83 inch IR interactive whiteboard Finger touch whiteboard
Description of IWB
MTHGH Interactive whiteboard is an ideal solution as alternative product of traditional projection screen, and is the BEST solution as projection board for interactive projectors.
We're with more than 10 years experience for infrared IWB, with own R&D team and Customize service, with free whiteboard software, different size for choice, with different color frame, both sides with short-cuts (or emtpy).
Application area: School Education, Business meeting/presentation, Hospital, Milatary, etc.
Technical specifications:
| Hardware Special Features |
Gesture recognition |
| Technology |
Infrared |
| Input Methods |
Finger, stylus, or any other opaque object |
| Touch Point |
10 touch points |
| Cursor Speed |
180 dot/s |
| Display ratio |
4:3, 16:9 16:10 |
| Resolution |
32768 x 32768 |
| Positioning Accuracy |
<2mm |
| Connecting Port |
USB 2.0 USB 1.1 USB 3.0 |
| View Angle |
Horizontal 170°, vertical 160° |
| Operating System |
Windows 2000, Windows XP, Windows Vista, Windows 7, Windows 8.1,Windows 10, Linux, Mac, Android |
| Power Supply |
USB power supply DC 4.6V- 5.0V <1W ( 100mA at 5V) |
| Working Condition |
Indoor or Outdoor |
| Storage |
Temperature: -30°C~60°C Humidity: 0%~95% |
| Operation |
Temperature: -10°C~45°C Humidity: 10%~90% |
| Installation |
Wall mounted, cabinets, mobile stand (optional) |
| Warranty |
3 years |
All-in-one projection surface — whiteboard surface is optimized for projection, with minimal glare or reflection, there are two surfaces for selection:
I. Nano matte surface
>> Standard projection surface, ideal solution for projection, but not support dry-erase.
II. Ceramic surface
>>If board is made with ceramic surface, it is dry-erase supporting and easy to clean — you can use water pen to write and just use cloth to clean.
>>Lasting durability (for ceramic surface option) —ceramic surface, aluminum frame, steel-backed construction and square miter corners provide quality you can count on for years, with a more than 20-year limited guarantee.
>> More expensive than nano surface.
>> glare or reflection little weaker than nano surface.
- If need other sizes for projector, please refer to other dimension drawings.
- Customized sizes are welcome if the order quantity is massitive.
Detail drawing:
83/86” 4:3 Interactive Whiteboard
IWB-83,IWB-86
Total Area Size: 1774 x 1279mm
Active Size: 1631 x 1223 mm
Total Area Diagonal Size: (86.1”) 2187 mm
Inner Diagonal Size: (83.7” ) 2126 mm
