75 Inch Multi Screen Splicing LCD Video Panel For Commercial Advertising

1

75" 3.5mm bezel

450/500 nits brightness,WLED Backlit,1920*1080 resolution,with 1080 P HDMI input

2

System controller

1 in 16output HDMI splitter

3

Bracket

POP out bracket for 49" lcd video wall

4

Standard Accessories

English Manual,IR Controller,Power Cables,RJ45 Cables,RS232-RJ45 Connector

5

Packing

4/5 screens in 1 wooden case

LCD Technology

75" Original  DID LCD

Active Screen Diagonal

75"

Total Bezel Width

1.8[mm]

Aspect Ratio

16:9

Physical Resolution

1920*1080

Backlight System

WLED

Luminance(nits)

500[cd/m2]

Contrast(typ)

3500:1

Viewing Angle

H 178°OR V 178°

Display Colors

8Bit,16.7[M]

Refresh Rate

60[Hz]

Response Time

<=6 ms

Life(hrs)

>60,000(hrs)

MTBF

>100,000[h]

Surface

Anti-glare

Power Supply

AC100~240V 50/60 HZ

Cooling

Low noise fans

Working Time Capacity

7*24*365[hours]

Working Temperature

0℃~50℃

Working Humidity

0.85

Storage Temperature

20~60°C Or 4~140°F

Storage Humidity

85% non-condensing

DVI-I DUAL LINK

1

HDMI input 2K

1

VGA input

1

RS232 IN

1

RS232 OUT

2

IR IN

1

AC IN

AC100v-240V

Color System Support

PAL/NTSC/SECAM

Control Type

IR Remote &Software Control

Menu Language

English or Chinese

Vertical/Horizontal Display

Support
