Specification | Type | Parameter | |
|
LCD size | 110" | |
Panel purchase standard | A grad | ||
Light source | D-LED | ||
Resolution | 3840 x 2160pixels | ||
Brightness | 400cd/m²(typ.) | ||
Contrast ration | 1300:1(typ.) | ||
Pixel pitch | 0.5622 (W) x 0.5622(H) | ||
Frequency | 60Hz | ||
Viewing Angle | 178 °(H)/178 °(V) | ||
Life span | 60,000hrs(min.) | ||
Response time | 8ms | ||
Color saturability | 75% | ||
Visual area | 2158.848×1214.352mm | ||
Display Colors | 1.06B | ||
|
|
Architecture | 64-bit architecture CPU and super G51 series GPU |
Working frequency | 1.5GHZ | ||
Number of cores |
8 cores |
||
Memory | DDR4: 4GB/eMMC:32GB | ||
System version | Android8.0 | ||
Chip solution | Hi3751ARBCV811 | ||
|
Voltage | AC100-240V~,100-260V~50/60Hz | |
Max. power consumption | ≤280W | ||
Standby power consumption | <0.5W | ||
Speaker | 1 x 10W(max) | ||
Power supply (AC) input | 100-240V | ||
Power switch | Rocker switch | ||
|
Working temperature | 0℃~40℃ | |
Storage temperature | -20℃~60℃ | ||
Working humidity | 10%~90% No condensation | ||
|
RJ45 N | 1 | |
Coax | 1 | ||
RS232 | 1 | ||
AV IN | 1 | ||
YPBPR | 1 | ||
PC AUDIO | 1 | ||
VGA | 1 | ||
VGA&DP TOUCH | 1 | ||
DP | 1 | ||
HDMI TOUCH | 2 | ||
HDMI | 2 | ||
USB FL | 1 | ||
USB | 1 | ||
TF | 1(Max.128g) | ||
|
RJ45 OUT | 1 | |
HDMI OUT | 1 | ||
Earphone | 1 |
Specification | Type | Parameters | |
|
USB | USB2.0 x 2;USB3.0 x 2 | |
LAN Interface | 1 | ||
HDMI OUT | 1 | ||
LINE-OUT | 1 | ||
MIC-IN | 1 | ||
OPS DC | 12V-19V 5A | 60W | |
|
USB3.0(FOLLOW) | 2 | |
TOUCH-USB(motherboard expansion) | 1 | ||
HDMI 2.0(motherboard expansion) | 1 | ||
|
Net weight | 138±1kg | |
Gross weight | 198±1kg | ||
Bare dimension | 2219.2 x 1339.7 x 112mm | ||
Packing dimension | 2525 x 435 x 1745mm(With pallet) | ||
Shell material | Aluminum alloy frame, sheet metal back cover | ||
Shell color | Frame(black+silver) back(black) | ||
Width of frame(T/B/L/R) | 29.4/60.6/13.8/13.8 mm | ||
VESA hole site | 4-M8Screw holes 600 x 800 mm | ||
Language | OSD | CN,EN etc | |
Audio-video |
Camera | 800WBuilt-in HD camera,3264*2448pixels | |
Microphone | Line array 6 Mic, intelligent noise reduction, sound pickup distance≦8M | ||
|
Touch specifications | Non-contact infrared sensing technology, support 20 points writing | |
Glass |
|
||
Glass transmittance | >88% | ||
Frame material | Aluminum alloy frame,PCBA | ||
Touch accuracy | ≤1mm | ||
Touch depth | 3±0.5mm | ||
Input mode | Opaque object (finger, pen, etc) | ||
Theoretical hits | Same position 60 million times above | ||
Light resistance | Incandescent lamp (220V, 100W), with a vertical distance of more than 350mm and solar illuminance of 90000Lux | ||
Power supply | USB(USB power supply) | ||
Supply voltage | DC 5.0±5% | ||
Accessory | Remoter | 1 | |
Power cord | 1(1.5M) | ||
Triangle fine pen | 1 | ||
Operation manual | 1(A4 folding) | ||
Battery | 1 | ||
WIFI antenna | 1 | ||
WIFI antenna | 4 |
Xingyicheng (Shenzhen) Technology Co., Ltd. was established in 2017. It is a national high-tech enterprise with core patents and an independent R&D team. It can provide customers with personalized OEM and ODM solutions. The main markets are North America, Europe, Russia, the Middle East, Southeast Asia, mainland China, etc.
Multiple Functions For One Device
Turn complex into simple. Multifunctional at the same time, follow one’s inclinations. A variety of functions are free to choose.
Vacuum Full Fit
Eliminate the air between the screen, secondary background colour optimization, greatly reduce light reflection, improve the clarity of the picture, highly restore the true colour, toughened glass, effective anti-glare, low reflection, protect students’ visual health.
Adjustable Thin and Narrow Joint
The adjustable thin and narrow stitching process is adopted to install the adjustable gap, and the joint gap is fine to <0.2mm.
Massive Resources for Easy Teaching
We support the development of educational resources, interactive teaching, remote tutoring and interest cultivation to make teaching easier.
Audio-visual Interactive Teaching
Flexible use of teaching tools, call high quality teaching resources to make the teaching process audio-visual combination, mobile phones, computers and interesting teaching interactive better.
Multi-touch Simultaneous Control
Capacitive touch control technology, can meet the needs of many people at the same time touch operation, up to 20 touch control, many people at the same time writing, do not interfere with each other, responsive, fast response to read.
