49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p

1 Set
MOQ
Negotiable
Price
49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: 49" LED Splicing Screen
Resolution: 3840*2160 Or 1920*1080
Power Supply: AC 180V~240V
Brightness: 500cd/m²
Type Of Light Source: WLED.
Perspective: 178*178
Input Control: 60,000 Hours
Enter: VGA/DVI/HDMI/AV/YPBPR
Operating Voltage: 60Hz
Working Humidity: 20%~80% No Condensation
Appendix: Power Cord, Certificate Of Conformity, Warranty Card And Manual
Highlight:

49 Inch Splicing Screen Lcd

,

4k Splicing Screen Lcd

Basic Infomation
Place of Origin: China
Brand Name: MTHGH
Certification: CE FCC
Model Number: XYC-49
Payment & Shipping Terms
Packaging Details: Standard carton package : carton+ plastic bag+ foam+ honeycomb paperboard+ pack thread.
Delivery Time: 7-10 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000 Piece
Product Description

MTHGH 49 Inch 4k Splicing Screen Lcd Panel AC 180-240V Resolution 1080P



MTHGH 3.5mm 49 inch competitive price and high quality LCD Video Wall



Item No. Components Descriptions
1 49" Mthgh 3.5mm bezel 500 nits brightness,WLED Backlit,1920x1080 resolution,with 1080P HDMI input
2 System controller 1 in 16output HDMI splitter
3 Bracket POP out bracket for 49" lcd video wall
4 Standard Accessories English Manual,IR Controller,Power Cables,RJ45 Cables,RS232-RJ45 Connector
5 Packing 4/5 screens in 1 wooden case
Panel Specifications

LCD Technology

Original Mthgh DID LCD.

Active Screen Diagonal

49 Inch

Total Bezel Width

1.8mm

Aspect Ratio

16:9

Physical Resolution

1920*1080

Backlight System

WLED.

Luminance(nits)

500 cd/m2

Contrast

3500:1 (typ.)

Viewing Angle

H 178°* V 178°

Display Colors

8Bit,16.7M

Refresh Rate

60 Hz

Response Time

<=6ms

Life(hrs)

>60,000(hrs)

MTBF

> 100,000 h

Surface

Anti-glare

Standby Power Consumption

<3W

Maximum Power Consumption

<=260W

Power Supply

AC100~240V 50/60 HZ

Cooling

Low noise fans

Working Time Capacity

7x24x365(hours)

Working Temperature

0~50℃

Working Humidity

0.85

Storage Temperature

-20~60°C | -4~140°F

Storage Humidity

85% non-condensing

Net Weight

26(kg/unit)

1080P HDMI input daisy chain board Signal Inputs, Outputs

DVI-I DUAL LINK

1.

HDMI input 2K

1

VGA input

1.

RS232 IN

1.

RS232 OUT

2

IR IN

1

AC IN

AC100-240V

Color System Support

PAL/NTSC/SECAM

Control Type

IR Remote &Software Control

Menu Language

English or Chinese

Vertical/Horizontal Display

Support



 49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 0

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 1

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 2

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 3

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 4

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 5

49 Inch 4k Splicing Screen LCD Panel Ac 180-240v Resolution 1080p 6
